The Automatic Drying Type Water-Based and Thermal Film Laminator is a high-efficiency machine designed for paper and plastic film lamination using both water-based and thermal processes. It is ideal for large-scale lamination tasks, especially with water-based adhesives, which are more eco-friendly compared to solvent-based alternatives.
This versatile, user-friendly machine features a simple one-button operation and combines electromagnetic and oil heating for fast, energy-efficient heating with high heat energy utilization. Its design ensures safety with a reliable external cover, while the hot knife slitting technology allows for precise slitting of various films (such as OPP, PET, and PVC) with adjustable settings for high accuracy.
| Hot cutter type | YS-SR108-S | YS-SR108-M | YS-SR108-L | YS-SR108-G | YS-SR130 |
| Chain cutter type | YS-SL108-S | YS-SL108-M | YS-SL108-L | YS-SL108-G | YS-SL130 |
| Standard type | YS-S108-S | YS-S108-M | YS-S108-L | YS-S108-G | YS-S130 |
| Speed | 20-100m/min | 20-100m/min | 20-100m/min | 20-100m/min | 20-100m/min |
| Applicable paper gram | 100-500g | 100-500g | 100-500g | 100-500g | 100-500g |
| The maximum available size | 1080×1000mm | 1080×1200mm | 1080×1450mm | 1080×1650mm | 1300×1650mm |
| The minimum available size | 300×350mm | 300×350mm | 300×350mm | 300×350mm | 300×350mm |
| Total electricity consumption | 60kw | 60kw | 60kw | 65kw | 65kw |
| Machine weight | 10000kg | 10000kg | 10500kg | 10800kg | 11500kg |
| Machine size | 11800×2370×3000mm | 11800×2370×3000mm | 12300×2370×3000mm | 13300×2370×3000mm | 13300×2590×3000mm |
Non-adjustable negative pressure adsorption, slide rail adjustment, saving time and effort.
The servo motor controls the pull gauge for automatic alignment, ensuring easy operation and accurate positioning.
Powerful four-feed, four-suction system for stable paper feeding. Continuous paper feeding without interruptions. Shaftless feeder with servo control system, offering flexible and convenient adjustments (standard configuration for 1450~1620 models). Full-page direct push type for reduced labor (optional).
Adopt double motors drive for gluing, the accuracy can reach 3g/Square meter; Use Tefon treatment to achieve high temperature resistance, non-sticky and other effects.
The vacuum pump is Baker brand.
One-key start, simple operation, hanging film device, can be operated by one person.
Electromagnetic heating and oil heating are now combined, with fast heating and high thermal energy utilization.
Three-sided paper flush device, counting function, corrugated paper output, automatic waste discharge, paper jam slowdown, automatic paper change optional), back flush (optional) counting and label insertion function (optional).
Hot knife slitting: Ideal for all types of films, particularly PET films, aluminized films, etc. It features high cutting speed, precise cuts, and clean tail cutting. The slit film is small, ensuring smooth entry into the next process.
Effectively remove dust on the surface of the paper, increase the brightness of the film, and save the amount of glue.Coding reserved platform.
Chain knife slitting: Designed for slitting PET films, it offers two cutting modes to ensure accurate cutting of various materials and paper colors.
Laminated products are specifically designed for high-end solid printing. They ensure minimal white spots on the film, enhancing both brightness and peel strength. These products are particularly well-suited for challenging processes, such as deep embossing in system applications.
Automatic intelligent paper change, reduce workers' work, improve work effciency.
Specially aimed at high-end ~ solid printing laminating products. lt greatly improves the brightness and peel strength of the product, and is especially suitable for diffcult and honest processes such as system deep embossing.
Electric hanging film and hydraulic lifting, choose one of the two.
Direct push-type paper loading reduces the need for manual laborDirect push,-type making paper loading the reduces process the more need efficient. for manual labor, making the process more efficient.
